Professional Chainsaws

565 AutoTune™

$1,899.00Rec. retail price incl. GST SKU: 966733920

Output shaft power3.7 kW
Cylinder displacement70.6 cm³

Product description

With outstanding cutting performance, the 565 will help you work faster even with long guide bars. Excellent cooling capacity and state-of-the art filtration means great performance and easy operation even for the toughest jobs. Equipped with AutoTune™ and Air Injection™ and with low vibration levels, the 565 is a powerful yet ergonomically designed chainsaw for fast, safe work.

Product Information

Features (13)

The clutch cover is designed to optimise rapid, safe saw chip ejection. Prevents clogging, even when cutting long fibre wood. image

Better chip ejection avoids clogging

Clutch cover design optimise chip ejection

The front handle bar position is close to the center of gravity, giving you better cutting control. image

Better manoeuvrability provides full control

Lowered handle gives better control

Give you full working days with maintained performance and less wear on the engine. image

Air Injection filters 98% of incoming dust

Maintains performance, gives less wear

AutoTune™ ensures a correctly tuned engine setting and optimised engine performance in all conditions. image

10 times quicker air/fuel mix adjustment

Correct engine setting and optimal performance

Husqvarna’s anti vibration system efficiently separates your hands from the vibrations generated by the engine and the cutting equipment. This is to protect your body but also to reduce the fatigue in your arms and hands and in the end of the day contribute to make your workday more productive. image

Low vibrations

Handles separated from engine

The innovative system for engine control is designed to provide a long engine life. The system monitors the engine and assures that the engine always is protected from over-revving. image

Soft cut-out system

Cut-out system prevents over-revving

Fuel Indicator

Transparent fuel indicator makes it easy to check fuel level

Flip up tank caps

Easy to open and secure

Perfect sight is critical when felling – so we made one that will outlast the chainsaw itself. image

Felling sight to last a lifetime

Perfect sight critical for felling

AutoTune

Automatic engine setting with AutoTune

Sturdily built crankcase withstands high rpms and tough professional use, ensuring a long service life. image

Magnesium crankcase

Magnesium crankcase designed for professional use

Smart Start® Technology

Specially-designed engine and starter for easy and fast starting with minimum effort

Delivers lower fuel consumption and reduced exhaust emission levels in accordance with the world's most stringent environmental regulations. image

Powerful and Efficient X-TORQ® Engine

Great power and efficiency

Specifications	Art No: 966733920
Output shaft power	3.7 kW
Weight (excl. cutting equipment)	6.5 kg
Chain speed at max power	20.7 m/s
Cylinder displacement	70.6 cm³
Fuel consumption	1.63 kg/h
Fuel tank volume	0.7 l
Sound pressure level at operators ear	105 dB(A)
Bar length	50 cm
Clutch engagement speed (±120)	3800 rpm
Electrode gap	0.5 mm
Equivalent vibration level (ahv, eq) front handle	5.2 m/s²
Equivalent vibration level (ahv, eq) rear handle	5.3 m/s²
Exhaust emissions (CO average) EU	227.51 g/kWh
Exhaust emissions (CO average) EPA	245.11 g/kWh
Exhaust emissions (HC average) EU	54.98 g/kWh
Exhaust emissions (NOx average) EU	2.33 g/kWh
Exhaust emissions (NOx average) EPA	2.26 g/kWh
Fuel consumption	442 g/kWh
Idling speed	2700 rpm
Maximum power speed	9300 rpm
Oil tank volume	0.35 l
Product size height	29.9 cm
Product size length	45.8 cm
Product size width	24.2 cm
Recommended bar length, max	28 in
Recommended bar length, max	70 cm
Recommended bar length, min	15 in
Recommended bar length, min	38 cm
Sound power level, guaranteed (LWA)	119 dB(A)
Sound power level, measured	117 dB(A)
Torque, max.	4.2 Nm
Torque, max. at rpm	6900 rpm
